Forklift Pinion

Forklift Pinion - The king pin, typically constructed out of metal, is the major pivot in the steering device of a vehicle. The first design was really a steel pin wherein the movable steerable wheel was connected to the suspension. Able to freely rotate on a single axis, it restricted the degrees of freedom of motion of the rest of the front suspension. During the 1950s, the time its bearings were replaced by ball joints, more detailed suspension designs became accessible to designers. King pin suspensions are nevertheless used on several heavy trucks because they have the advantage of being capable of lifting much heavier cargo.

New designs no longer limit this particular device to moving like a pin and nowadays, the term might not be used for a real pin but for the axis around which the steered wheels pivot.

The KPI or also known as kingpin inclination can likewise be referred to as the SAI or steering axis inclination. These terms define the kingpin if it is places at an angle relative to the true vertical line as looked at from the front or back of the forklift. This has a vital impact on the steering, making it likely to return to the straight ahead or center position. The centre position is where the wheel is at its peak position relative to the suspended body of the forklift. The vehicles' weight has the tendency to turn the king pin to this position.

Another effect of the kingpin inclination is to set the scrub radius of the steered wheel. The scrub radius is the offset between the projected axis of the steering down through the kingpin and the tire's contact point with the road surface. If these points coincide, the scrub radius is defined as zero. Though a zero scrub radius is likely without an inclined king pin, it requires a deeply dished wheel so as to maintain that the king pin is at the centerline of the wheel. It is a lot more sensible to incline the king pin and make use of a less dished wheel. This also provides the self-centering effect.
